B-78 B30 Bus Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F143
UR_UINT32: 32 BIT ERROR CODE (F141 specifies bit number)
A bit value of 0 = no error, 1 = error
F144
ENUMERATION: FORCED CONTACT INPUT STATE
0 = Disabled, 1 = Open, 2 = Closed
F146
ENUMERATION: MISCELLANEOUS EVENT CAUSES
F152
ENUMERATION: SETTING GROUP
0 = Active Group, 1 = Group 1, 2 = Group 2, 3 = Group 3
4 = Group 4, 5 = Group 5, 6 = Group 6
F155
ENUMERATION: REMOTE DEVICE STATE
0 = Offline, 1 = Online
F156
ENUMERATION: REMOTE INPUT BIT PAIRS
81 Module Failure 08
82 Module Failure 09
83 Incompatible H/W
84 Module Failure 10
85 Module Failure 11
86 Module Failure 12
87 High ENET Traffic
89 Relay Restart
90 FGM Failure
91 FGM Failure
92 FGM Failure
93 FGM Failure
94 FGM Failure
95 FGM Error
96 Maintenance Alert
97 PHY Monitor
98 Storage Media Alarm
99 Wrong Transceiver
100 Power Supply Warning
Bitmask Definition
0 Events Cleared
1 Oscillography Triggered
2 Date/time Changed
3 Default Settings Loaded
4 Test Mode Forcing On
5 Test Mode Forcing Off
6 Power On
7 Power Off
8 Relay In Service
9 Relay Out Of Service
10 Watchdog Reset
11 Oscillography Clear
12 Reboot Command
13 Led Test Initiated
14 Flash Programming
15 Fault Report Trigger
16 User Programmable Fault Report Trigger
17 ---
18 Reload CT/VT module Settings
Bitmask Error
19 ---
20 Ethernet Port 1 Offline
21 Ethernet Port 2 Offline
22 Ethernet Port 3 Offline
23 Ethernet Port 4 Offline
24 Ethernet Port 5 Offline
25 Ethernet Port 6 Offline
26 Test Mode Isolated
27 Test Mode Forcible
28 Test Mode Disabled
29 Temperature Warning On
30 Temperature Warning Off
31 Unauthorized Access
32 System Integrity Recovery
33 System Integrity Recovery 06
34 System Integrity Recovery 07
Bitmask Value Bitmask Value
0 None 35 UserSt-3
1 DNA-1 36 UserSt-4
2 DNA-2 37 UserSt-5
3 DNA-3 38 UserSt-6
4 DNA-4 39 UserSt-7
5 DNA-5 40 UserSt-8
6 DNA-6 41 UserSt-9
7 DNA-7 42 UserSt-10
8 DNA-8 43 UserSt-11
9 DNA-9 44 UserSt-12
10 DNA-10 45 UserSt-13
11 DNA-11 46 UserSt-14
12 DNA-12 47 UserSt-15
13 DNA-13 48 UserSt-16
14 DNA-14 49 UserSt-17
15 DNA-15 50 UserSt-18
16 DNA-16 51 UserSt-19
17 DNA-17 52 UserSt-20
18 DNA-18 53 UserSt-21
19 DNA-19 54 UserSt-22
20 DNA-20 55 UserSt-23
21 DNA-21 56 UserSt-24
Bitmask Definition
