M1110147 Rev. 5 © 2007 Datex-Ohmeda. All rights reserved. 9-1
Chapter 9
Specifications
Note: All specifications are nominal and are subject to change without notice.
Electrical Specifications
Input 1.5 A @ 100 – 240 V~, 50/60 Hz
Fuses T3.15A @ 250V~, slo-blo type (qty. 2)
Leakage Current < 300 µA @ 264 V~
Ground impedance < 0.1 ohm from ground pin of the power inlet
module to any exposed metal surface.
Environmental Operating Conditions
Ambient temperature +10°C to +35°C (50 to 95°F).
Humidity 10% to 90% RH non-condensing
Atmospheric pressure 70 kPa to 106 kPa
Storage Requirements
Temperature -40°C to +70°C (-40 to 158°F).
Humidity 0% to 100% RH non-condensing
Atmospheric pressure 50 kPa to 106 kPa
