GE C60 User Manual

GE Multilin C60 Breaker Protection System B-43
APPENDIX B B.4 MEMORY MAPPING
B
74AF Disconnect Switch 1 Phase A / Three-pole Opened 0 to 4294967295 --- 1 F300 0
74B1 Disconnect Switch 1 Phase B Closed 0 to 4294967295 --- 1 F300 0
74B3 Disconnect Switch 1 Phase B Opened 0 to 4294967295 --- 1 F300 0
74B5 Disconnect Switch 1 Phase C Closed 0 to 4294967295 --- 1 F300 0
74B7 Disconnect Switch 1 Phase C Opened 0 to 4294967295 --- 1 F300 0
74B9 Disconnect Switch 1 Operate Time 0 to 65.535 s 0.001 F001 70
74BA Disconnect Switch 1 Alarm Delay 0 to 65.535 s 0.001 F003 0
74BC Disconnect Switch 1 Events 0 to 1 --- 1 F102 0 (Disabled)
74BD Reserved (2 items) --- --- --- F001 0
74BF ...Repeated for Disconnect Switch 2
74DE ...Repeated for Disconnect Switch 3
74FD ...Repeated for Disconnect Switch 4
751C ...Repeated for Disconnect Switch 5
753B ...Repeated for Disconnect Switch 6
755A ...Repeated for Disconnect Switch 7
7579 ...Repeated for Disconnect Switch 8
7598 ...Repeated for Disconnect Switch 9
75B7 ...Repeated for Disconnect Switch 10
75D6 ...Repeated for Disconnect Switch 11
75F5 ...Repeated for Disconnect Switch 12
7614 ...Repeated for Disconnect Switch 13
7633 ...Repeated for Disconnect Switch 14
7652 ...Repeated for Disconnect Switch 15
Thermal Overload Protection (Read/Write Settings) (2 modules)
7788 Thermal Protection 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7789 Thermal Protection 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
778A Thermal Protection 1 Base Current 0.2 to 3 pu 0.01 F001 80
778B Thermal Protection 1 K Factor 1 to 1.2 --- 0.05 F001 110
778C Thermal Protection 1 Trip Time Constant 0 to 1000 min. 1 F001 45
778D Thermal Protection 1 Reset Time Constant 0 to 1000 min. 1 F001 45
778E Thermal Protection 1 Minimum Reset Time 0 to 1000 min. 1 F001 20
778F Thermal Protection 1 Reset 0 to 4294967295 --- 1 F300 0
7791 Thermal Protection 1 Block 0 to 4294967295 --- 1 F300 0
7793 Thermal Protection 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7794 Thermal Protection 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7795 Reserved (2 items) --- --- --- F001 0
7797 Repeated for Thermal Protection 2
Ohm Inputs (Read/Write Setting) (2 modules)
77F8 Ohm Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
77F9 Ohm Inputs 1 ID --- --- --- F205 "Ohm Ip 1 "
77FF Ohm Inputs 1 Reserved (9 items) 0 to 65535 --- 1 F001 0
7808 ...Repeated for Ohm Inputs 2
Phasor Measurement Unit Recorder Config Counter Command (Read/Write Command) (2 modules)
781A PMU 1 Recorder Clear Config Counter 0 to 1 --- 1 F126 0 (No)
781B ...Repeated for PMU 2
Phasor Measurement Unit One-shot Command (Read/Write Setting)
788C PMU One-shot Function 0 to 1 --- 1 F102 0 (Disabled)
788D PMU One-shot Sequence Number 0 to 99 --- 1 F001 1
788E PMU One-shot Time 0 to 235959 --- 1 F050 0
Phasor Measurement Unit Recording Values (Read Only) (2 modules)
7890 PMU 1 Available Records 0 to 65535 --- 1 F001 0
7891 PMU 1 Second Per Record 0 to 6553.5 --- 0.1 F003 0
7893 PMU 1 Last Cleared Date 0 to 400000000 --- 1 F050 0
7895 ...Repeated for PMU 2
Table B–10: MODBUS MEMORY MAP (Sheet 35 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
