GE C60 User Manual

B-44 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Phasor Measurement Unit Test Values (Read/Write Setting) (2 modules)
78AE PMU 1 Test Function 0 to 1 --- 1 F102 0 (Disabled)
78AF PMU 1 Phase A Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78B1 PMU 1 Page A Voltage Test Angle -180 to 180 ° 0.05 F002 0
78B2 PMU 1 Phase B Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78B4 PMU 1 Phase B Voltage Test Angle -180 to 180 ° 0.05 F002 -12000
78B5 PMU 1 Phase C Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78B7 PMU 1 Phase C Voltage Test Angle -180 to 180 ° 0.05 F002 12000
78B8 PMU 1 Auxiliary Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78BA PMU 1 Auxiliary Voltage Test Angle -180 to 180 ° 0.05 F002 0
78BB PMU 1 Phase A Current Test Magnitude 0 to 9.999 kA 0.001 F004 1000
78BD PMU 1 Phase A Current Test Angle -180 to 180 ° 0.05 F002 -1000
78BE PMU 1 Phase B Current Test Magnitude 0 to 9.999 kA 0.001 F004 1000
78C0 PMU 1 Phase B Current Test Angle -180 to 180 ° 0.05 F002 -13000
78C1 PMU 1 Phase C Current Test Magnitude 0 to 9.999 kA 0.001 F003 1000
78C3 PMU 1 Phase C Current Test Angle -180 to 180 ° 0.05 F002 11000
78C4 PMU 1 Ground Current Test Magnitude 0 to 9.999 kA 0.001 F004 0
78C6 PMU 1 Ground Current Test Angle -180 to 180 ° 0.05 F002 0
78C7 PMU 1 Test Frequency 20 to 70 Hz 0.001 F003 60000
78C9 PMU 1 Test df/dt -10 to 10 Hz/s 0.01 F002 0
78CA ...Repeated for PMU 2
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F137 0 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 4294967295 --- 1 F300 0
7B84 User Programmable Pushbutton 1 Autoreset Delay 0.2 to 600 s 0.1 F001 10
7B85 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B86 User Programmable Pushbutton 1 Local Lock Operand 0 to 4294967295 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B89 User Programmable Pushbutton 1 Remote Lock Operand 0 to 4294967295 --- 1 F300 0
7B8B User Programmable Pushbutton 1 Reset Operand 0 to 4294967295 --- 1 F300 0
7B8D User Programmable Pushbutton 1 Set Operand 0 to 4294967295 --- 1 F300 0
7B8F User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B90 ...Repeated for User Programmable Pushbutton 2
7BC0 ...Repeated for User Programmable Pushbutton 3
7BF0 ...Repeated for User Programmable Pushbutton 4
7C20 ...Repeated for User Programmable Pushbutton 5
7C50 ...Repeated for User Programmable Pushbutton 6
7C80 ...Repeated for User Programmable Pushbutton 7
7CB0 ...Repeated for User Programmable Pushbutton 8
7DE0 ...Repeated for User Programmable Pushbutton 9
7D10 ...Repeated for User Programmable Pushbutton 10
7D40 ...Repeated for User Programmable Pushbutton 11
7D70 ...Repeated for User Programmable Pushbutton 12
7DA0 ...Repeated for User Programmable Pushbutton 13
7DD0 ...Repeated for User Programmable Pushbutton 14
7E00 ...Repeated for User Programmable Pushbutton 15
7E30 ...Repeated for User Programmable Pushbutton 16
Table B–10: MODBUS MEMORY MAP (Sheet 36 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
