18
Using the vaporizer
Use only Selectatec™ Series Vaporizers Tec™ 6
Plus Vaporizer or greater.
1. Turn the lock lever full clockwise to lock the
vaporizer in position.
2. Push the release and turn the concentration
control to set the agent concentration.
Lock lever
Fill port and cap
Concentration
control and release
Using the ACGO
1. Open the ACGO switch cover.
2. Set the ACGO switch to the
ACGO position.
• Fresh gas ows through the
ACGO port.
• Fresh gas oxygen
concentration is displayed
on the screen if the system
has the airway module
option.
3. Set the alarm limits to clinically
appropriate settings.
4. To stop fresh gas ow through
the ACGO port, set the ACGO
switch to the circle circuit
position.
1
1
2
2
