Hardware Installation IST 005 (C) 1280 x 1024 Landscape Monitor Interconnections
Page 48
Illustration 3-10: connection oF two landscape monitors
3-7 Video Board Driver Installation
Refer to job card SW 003 in chapter 6 for C monitor video board driver installation instructions.
Slot 4
Slot 3
Interface interconnections
to two landscape monitors
Video Card
Blank
Blank
Video Card
Landscape
Monitor 1
Slot 1
Slot 2
Slot 5
Slot 6
Blank
Blank
Landscape
Monitor 2
