– 21 –
Control Board Connections
CN1 - Inlet High Limit, Heater
CN2 - Neutral
CN4 - DC output to Thermistor, Touch Sensor, Lamp
RY1- Motor Relay
RY6 - Heater Relay
RY6
RY1
CN4
CN2
CN1
