Rear panel of (optional) battery extension pack:
15 DC socket (14Ah only).
15a DC connector
16 Slots to fasten cable clamps.
18 Battery fuse holder(s)
7Ah: 2 fuses
14Ah: 4 fuses
OPM_LPE_11X_3K0_10K_1GB_V041 17 GE DE LP 11 UPS: User manual 4.1 (GB)
Figure 13. Rear panel battery
extension pack (optional)
19
15a
18
15
Rear panel of (optional) battery extension pack,
equipped with swivel:
15 DC socket (14Ah only)
15a DC connector
18 Battery fuse holder(s)
7Ah: 2 fuses
14Ah: 4 fuses
19 Swivel to fasten cable in terminal cover of UPS
Figure 13a. Rear panel battery
extension pack (optional)
equipped with swivel
