10 - Specifications
UPS Type : LP 3-11 LP 5-11 LP 6-11 LP 8-11 LP 10-11
Output power (kVA/kW) : 3/2.4 5/4 6/4.8 8/6.4 10/8
AC input voltage : 220-240Vac
Input frequency : 50/60 Hz
AC output voltage : 230V
Output frequency : 50 or 60 Hz, std. 50 Hz; selectable on front
System efficiency (full load) : 88%
Line input breaker (MCB, D-type) : 32A 32A 32A 40A 50A
Bypass input breaker (MCB, D-type) : 32A 32A 32A 40A 50A
Input/output connectors : terminals at rear of unit
INPUT
AC input voltage range
at 100% load : 172 - 285 V
at 50% load : 147 - 285 V
at 25% load : 132 - 285 V
Input frequency range : 40-70 Hz
Input current wave form : sinusoidal
Input power factor : ≥ 0.99
Max. input current (A) : 16 28 28 40 50
Inrush current : none
DC output voltage : 380 V
BATTERY CHARGER
Characteristic : U/I-characteristic, constant current charging until float voltage, then constant
voltage charging and boost charge mode for fast recharging of batteries
DC input voltage range : 350-450 V
DC output voltage at 20 °C
LP 3-11 : float: 162.5 V boost: 177 V
LP 5/6/8/10-11 : float: 274 V boost: 295 V
Output current limit (Adc) : 2.0 2.0 2.0 3.6 3.6
OUTPUT CONVERTER
Output power at pf. = 0.8, VA* : 3000 5000 6000 8000 10000
Semiconductor : IGBT
AC output voltage nominal : 220/230/240V (user selectable)
Output voltage tolerance : ± 1% static resistive load
± 2% measured crest load 2.5:1
± 2% dynamic mean deviation over one half cycle for 100% of rated load
applied or removed
Typical overload : 110% ≥ 20 minutes
(temp. dependent) 130% ≥ 3.5 minutes
150% ≥ 2 minutes
Output frequency : 60 or 50 Hz selectable, ± 0.1%, unless synchronized with the mains
Freq. tracking range : ± 2/4/6% of nominal, user selectable
Output wave form : sine wave
Max. phase difference input-output : max 7°
Harmonic distortion : 2% max. with linear load
Power factor range : Any lagging or leading power factor is permitted within the specified rating to
pf. 0.5
Output derating altitude : Till 1000m no derating
Above 1000m 12.5% per 1000m, max. 4000m
Protection : Automatic shut down (or transfer to bypass, if bypass is available) in case of
- low/high DC voltage
- overtemperature
- overload / short circuit
The output is protected against connection to the mains
* according to EN 50091-1
OPM_LPE_11X_3K0_10K_1GB_V041 33 GE DE LP 11 UPS: User manual 4.1 (GB)
