The output is switched off due to a faulty situation, indicated by the second
line.
OUTPUT OFF
NO INPUT POWER
The output will be switched off via the RS232 interface. The second line
indicates the time until shutdown.
PROG. SHUTDOWN
WITHIN 0:09:17
The output is switched off by a remote command (RS232/SNMP). The second
line indicates the time until wake-up.
PROG. SHUTDOWN
LEFT 0:14:03
The output is switched off by the 'no-load shutdown' feature: no input voltage
and no load. If the input voltage is restored, the output will be available again.
SHUTDOWN
ALARM (PRESS UP)
The wire on connector J3 pin 3-4 (rear panel, plug-in card 12) is interrupted.
The output is no longer available. To restart the unit, restore the connection
and turn the on/off switch (rear panel, 7) off and on again.
IMMEDIATE
SHUTDOWN
5.3.3 Service menu
When the default screen is displayed you can enter the first service screen by pressing the keys ‘Down’ (2) and
'Enter/Reset' (3) simultaneously for approx. 1 second. Using the ‘Up’ (4) and ‘Down’ (2) keys you can scroll
through several service screens.
The intro service screen. 'Enter/Reset' returns to the default screen.
SERVICE SCREENS
ENTER exit
The serial number of the UPS.
SERIAL NUMBER
l051/01 0020A0307A
Release number of the installed software and production code of the UPS.
SOFTWARE VERSION
R1.0; 640777
FAN SPEED 10
INV.DC: + 375
Service information about fan speed (min. 10, max. 30) and internal DC
voltage.
HEATSI.TEMP: 0
TRANSF.TEMP: 310
Service information on internal temperature levels, values in mV over the
temperature sensors.
Upper line: ‘1’ = batteries have reached float voltage.
FLOAT CHARGE: 1
OUTPUT FAST : 0
Second line: service information on output converter.
Service information on internal timer.
TSTAMP Q4
6028773 1
Frequency tracking range: output converter frequency will follow the bypass
frequency within these limits before returning to its own internal frequency.
Standard setting: nominal ±2%. Can be changed into nominal ±4% or ±6%.
See 5.3.4 Set-up Menu.
FREQ RANGE: 2%
NO LOAD : 1
No-load shutdown: after a 10 minutes delay the UPS will shut down during
utility failure if the load is < 2%. It will restart after the mains returns or when
the unit is switched off and on again.
Default setting = 1 (active). For disabling this feature see 5.3.4.
Start of the manual Quick Battery Test.
QUICK BATTERY
TEST PRESS ENTER
See for more information section 5.4.2 'Quick battery test'
OPM_LPE_11X_3K0_10K_1GB_V041 22 GE DE LP 11 UPS: User manual 4.1 (GB)
