Start of the manual Deep Battery Calibration Test.
CALIBRATE BAT
PRESS DOWN+ENTER
See for more information section 5.4.3 'Deep battery calibration test'
Service information on internal UPS components
PF1 THYRISTOR 1
BATT.THYRISTOR 0
Service information on internal UPS components
VSS THYRISTOR 0
PF1. CONVERTER 1
Service information on internal UPS components
BAT CHARGER 2
INVERTER 1
Batt.Charger: 0 = off, 1 = float charging; 2 = boost charging
Duration of latest test performed, hh/mm/ss
LAST TEST TIME
0:00:00
The UPS transfers the load to bypass when the keys ‘Down’ (2) and
'Enter/Reset' (3) on the front panel are pressed simultaneously for approx. 2
seconds. If the bypass supply is not within limits, the lower line will show the
text 'UNAVAILABLE'.
FORCE BYPASS
press DOWN+ENTER
Service set-up information whether the bypass is enabled (default) or disabled.
If disabled: UPS will NOT go to bypass. For disabling the bypass refer to the
set-up menu (5.3.4).
AUTOMATIC BYPASS
ENABLED
BATTERY 7Ah
BAT. CHARGE 86%
Service set-up information about the total battery capacity and the actual
battery charge condition. For changing the programmed battery capacity refer
to the set-up menu (5.3.4).
Service set-up information about frequency tracking speed for the inverter to
follow the bypass frequency, LOW (1Hz/sec.) is the normal value and default.
HIGH (5Hz/sec.) may be suitable if the UPS is connected to a generator with
fast frequency changes and the UPS must be synchronized to prevent alarms.
For changing the lock speed refer to the set-up menu (5.3.4).
PLL LOCK SPEED
NORMAL
Service set-up information about the ECO-mode. By pressing ‘Enter/Reset’
the ECO-mode can be enabled or disabled, depending on the actual status.
In this way the load will be supplied by way of the electronic bypass. If the
ECO-mode is disabled the load will be supplied by the inverter. See also
5.5.5.
IEMMODE DISABLED
ENTER/RESET CHNG
Service set-up information about the auto-restart function. This function can
be switched on or off by pressing ‘Enter/Reset’, depending on the actual
status. See also 4.5.5.1 step 6.
AUTO RESTART ON
ENTER/RESET CHNG
OPM_LPE_11X_3K0_10K_1GB_V041 23 GE DE LP 11 UPS: User manual 4.1 (GB)
