LP 8/10-11 installation drawing
Model Heat dissipation Dimensions Bottom
100% load 50% load h w d
Weight
Air flow
100%
load
Amb.
temp.
Rel.
humidity
non-cond.
Altitude
(max 4000m)
Branch
protec-
tion
slow
Input/output
wiring
Minimum free space
required
front side rear
x y
LP W Btu/hr W Btu/hr mm mm mm kg m3/hr °C % m A mm2 AWG mm mm mm mm mm
8-11 872 2976 520 1774 680 313 720 165 660 -10-40 <95 50 10 8 100 50 200 184 578
10-11 988 3371 545 1860 680 313 720 170 660 -10-40 <95
<1000, derating
12.5% per 1000
50 10 8 100 50 200 184 578
CASTORS
w
h
d
5 - COMMON
9 - GENERAL ALARM
4 - NOT USED
8 - MAINS FAILURE
3 - SERIAL DATA IN / UPS SHUTDOWN
7 - PLUG&PLAY / RTS
2 - SERIAL DATA OUT
6 - BYPASS ACTIVE
1 - BATTERY LOW
INPUT OUTPUT
EARTH CONNECTION
IS ESSENTIAL
1-2 BATTERY
DISCONNECTED
3-4 EMERGENCY
SHUTDOWN
RPA CARD
PARALLEL OPERATION
SNMP CARD OR RELAY CARD
RS232 / CONTACT, SEE BELOW
OFF
ON
STATIC
BYPASS
MAINS
UPS
MANUAL BYPASS SWITCH
BATTERY PACK CONNECTOR
CONTROLS / FUSES
OPTION SLOTS
RS232 / CONTACT INTERFACE
SUB-D PINNING
I/O TERMINALS
CABLE CLAMPS
NORMAL: POSITION 1
(LOAD ON UPS)
SERVICE: POSITION 2
(LOAD ON BYPASS)
