GE Evolve - Section 1: Light Engine(S) out

Evolve™ LED Area Light
Scalable Fixtures (EAS)
Troubleshooting
and Repair Guide
Section 1: Light Engine(s) Out (continued)
Left Light Engine
Power Door
Captive
Screws
Captive
Screws
EASC Assembly
Power door in open position with major components identified.
Light Engine
Cables
Name plate
LED Drivers
Wiring
Diagram
Terminal Board
LED Driver
input leads
Cables
