GE Evolve - EASC Assembly Connection Checks

Evolve™ LED Area Light
Scalable Fixtures (EAS)
Troubleshooting
and Repair Guide
Section 1: Light Engine(s) Out (continued)
EASC Assembly View
*Actual shape and color of connectors may vary.
Incoming
leads to
fixture
Outgoing
leads to
fixture
Pull back gently
on leads. They should
not disengage
Pull back gently on leads.
They should not disengage
Primary disconnect
