– 61 –
Bottle Wash System (some models)
The Bottle Wash is designed to wash sports bottles, baby bottles or any dishwasher safe container with a
smaller mouth which blocks water from entering the container using normal spray arm jets. This feature
insures clean containers. Water is active anytime that the upper spray arm is operational.
Selecting the bottle wash option on the control changes the wash algorithm. The upper spray arm and bottle
wash jets are cycled a longer time, and 23 minutes is added to most cycles when selected. Illustrations for
the bottle wash system and removal may be found in the Upper Rack section of this guide.
Upper Spray System
The upper sprayer provides a gentle shower down to the top rack.
The spray bracket is attached to the main conduit by means of tabs.
To remove the upper spray system, use a small screwdriver to release the spray system bracket tabs from
the main conduit.
Bottle Wash Hose
Bottle Wash Hose Cover
Bottle Wash Minifold
Bottle Wash Clips
Top
Sprayer
Main Conduit
Mounting Tabs
To Next Page
