Operating Instructions Installation InstructionsTroubleshooting Tips
Consumer Support
Safety Instructions
6
Electric Dryer
FOR YOUR SAFETY:
Use only rigid metal or ÀexiEle metal 4-in. diameter
ductwork for exhausting to the outdoors. Never use plastic
or other comEustiEle, easy-to-puncture ductwork.
This appliance must Ee properly grounded and installed as
descriEed in these instructions.
Do not install or store appliance in an area where it will Ee
exposed to water and/or weather.
This dryer must Ee exhausted to the outdoors.
Inspect the dryer exhaust outlet and straighten the outlet
walls if they are Eent.
Do not allow children on or in the appliance. Close
supervision of children is necessary when the appliance is
used near children.
BEFORE YOU BEGIN:
IMPORTANT - Save these instructions for local
inspector’s use.
IMPORTANT - OEserve all governing codes and
ordinances.
Note to Installer - Be sure to leave these instructions with the
customer.
Note to Customer - Keep these instructions with your Use
and Care Book for future reference.
Before the old dryer is removed from service or discarded,
remove the dryer door.
Service information and the wiring diagram are located in the
control console.
Install the dryer where the temperature is aEove 1 C 5F
for satisfactory operation of the dryer control system.
Read these instructions completely and carefully.
NOTE: Installation and service of this dryer requires basic mechanical and electrical skills. It is your responsibility to contact a
TXDOL¿HGLQVWDOOHUWRPDNHWKHHOHFWULFDOFRQQHFWLRQV
Step 1 Prepare the area and exhaust for installation of
new dryer see section 1.
Step 2 Check and ensure the existing external exhaust is
clean see section 1 and meets attached
installation speci¿cations see section 3.
Step 3 Remove the foam shipping pads see section 1.
Step 4 0ove the dryer to the desired location.
Step 5 Connect the power supply see section 2.
Step 6 Connect the external exhaust see section 4.
Step Level your dryer see section 5.
Step 8 Check the operation of the power supply and
venting.
Step 9 Place the owners Use and Care in a location
where it will Ee noticed Ey the owner.
For alcove or closet installation, see section 6.
For Eathroom or Eedroom installation, see section .
For moEile or manufactured home see, section 8.
For side or Eottom exhaust, see section 9.
TOOLS YOU
WILL NEED
MATERIALS YOU
WILL NEED
SLIP JOINT PLIERS
LEVEL
FLAT BLADE SCREWDRIVER
1O cm 4 in. DIA.
0ETAL DUCT RECO00ENDED
1O cm 4 in.
0ETAL ELBOW
EXHAUST
HOOD
DUCT TAPE
GLOVES
SAFETY GLASSES
1O cm 4 in. DUCT
CLA0PS 2
OR
1 cm 4 in. SPRING
CLA0PS 2
1O cm 4 in. DIA. FLEXIBLE 0ETAL
DUCT IF NEEDED
PHILLIPS SCREWDRIVER
WARNING!
