Lower Oven Light Does Not Work
Enter the service mode and
turn the lower oven lights on.
Are the lower lights on?
No
Remove the halogen bulbs.
Is 120 VAC present from the LORB
relay K16 NO contact to AC IN (L1)?
Yes
No
Is 120 VAC present from the
LORB relay K16 NO contact to the
EMI filter board IN1 contact?
Yes
Is 120 VAC present from the
LORB relay K16 NO contact to the
EMI filter board OUT1 contact?
Yes
Is 120 VAC present from the
LORB relay K16 NO contact to
the halogen lamp sockets?
Yes
Is 120 VAC present from the positive
contact to the negative contact of the
halogen lamp sockets?
Yes
Replace the
halogen bulb.
Is 120 VAC present from
the LORB relay K16 COM
contact to AC IN (L1)?
No
Is 120 VAC present from
the EMI filter board OUT2
contact to AC IN (L1)?
No
Is 120 VAC present from
the EMI filter board IN2
contact to AC IN (L1)?
No
Repair the faulty wiring
from AC IN (NT) to the
EMI filter board.
Repair the faulty wiring
from L1 input to the
EMI filter board.
No
No
Replace the EMI
filter board.
Repair the faulty wiring
from the EMI filter board
to the lamp sockets.
No
Repair the faulty wiring
from the LORB relay
K16 NO contact to the
lamp sockets.
No
Yes
Replace the EMI
filter board.
Yes
Open the lower oven door.
Are the lower lights on?
No
Yes
Replace the
plunger switch.
Yes
Is 0 VDC present from
the LORB connectors
J4, pin 10 to J5, pin 2?
Yes No
Replace
the MLB.
Replace
the LORB.
Repair the faulty wiring
from the LORB relay K16
COM contact to the EMI
filter board.
