1–6 LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
ORDERING CHAPTER 1: INTRODUCTION
1.4 Ordering
1.4.1 Order Codes
The order codes for the LM10 Motor Protection System are shown below.
Table 1–1: LM10 Order Codes
LM10 – D* – CT** – GF** – C* – **
Base unit LM10|||||LM10 Motor Protection System
Programmable
display unit
X | | | | No display unit
1 | | | | Programmable display unit (with
cable)
Thermal overload
current transformer
XX | | | No phase current transformer
01 | | | Current sensor, NEMA starter size
1, 3-phase, 27 A
02 | | | Current sensor, NEMA starter size
2 and 3, 3-phase, 90 A
03 | | | Current sensor, NEMA starter size
4, 3-phase, 200 A
04 | | | Current sensor, NEMA starter size
5, 1-phase, 300 A
05 | | | Current sensor, NEMA starter size
6, 1-phase, 600 A
Ground fault sensor XX | | No ground fault sensor
01 | | Ground fault sensor: 20 A, 0.44"
window
02 | | Ground fault sensor: 20 A, 1.56"
window
03 | | Ground fault sensor: 20 A, 2.08"
window
04 | | Ground fault sensor: 20 A, 2.50"
window
05 | | Ground fault sensor: 20 A, 3.31"
window
06 | | Ground fault sensor: 20 A, 4.62"
window
Cable X|No cable
1 | 30-inch communication cable
from relay to PC
Reserved XX For future use
