CHAPTER 1: INTRODUCTION SPECIFICATIONS
LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 1–11
Connector type:...............................................5-pin micro-style molded male connector
Baud rate: ..........................................................125, 250 and 500 kbps via DIP switches
Mac id: .................................................................0 to 63 via DIP switches
Supports:............................................................Poll, COS and Cyclic IO, and explicit messaging
LEDs:.....................................................................network status and device status
SERIAL COMMUNICATIONS
Serial port: .........................................................RJ11 4-pin connector for Enervista LM10 Setup software
or to PDU
PANEL DISPLAY UNIT (OPTIONAL)
Display:................................................................16 character × 4 line display
1.5.8 Environmental
AMBIENT TEMPERATURE
Operating temperature:..............................0 to 60°C
Storage temperature:...................................–30 to 80°C
HUMIDITY
Humidity:............................................................up to 95% non condensing
1.5.9 Approvals/Certification
CERTIFICATION
UL: ........................................................................file number E228903 listed for USA and Canada
CE:..........................................................................conforms to EN 55011, EN 61000, IEC 68-2
DeviceNet CONFORMANCE TESTED™
