4.3 Status Values
4.3.1 Main Menu
The main menu for the status values is shown below. Press the STATUS key to access these
values.
GE LM10 1.70
Class: 10
MAC ID: 1
Baud: 500
Status Active
Ready to Run
Range: Running 1, Running 2, Ready to
Run, Fault
Status Active
Phase A: 0.0
Range: 0.0 to 3200.0 A
Status Active
Phase B: 0.0
Range: 0.0 to 3200.0 A
Status Active
Phase C: 0.0
Range: 0.0 to 3200.0 A
Status Active
GndAmps: 0.0
Range: 0.0 to 25.0 A
Status Active
VOLTs: 220
Range: 0 to 9000 V
Status Active
PowFact: 0.00
Range: 0.00 to 1.00
Status Active
KW: 0.0
Range: 0.0 to 6553.5 kW
Status Active
Avg Cur: 0.0
Range: 0.0 to 3200.0 A
Status Active
%CurUnBl: 0
Range: 0 to 250%
Status Active
Motor Hrs: 0
Range: 0 to 65535 hours in steps of 1
