4.4 History Values
4.4.1 Last Trip Data
Data for the last ten trips is stored in the LM10. Press the HISTORY key to access these
values. Pressing the HISTORY key multiple times scrolls between trips 1 to 10.
GE LM10 1.70
Class: 10
MAC ID: 1
Baud: 500
Last Trip #1
Overcurrent
Range: Overcurrent, Gr. Fault, Jam, Stall,
CuUnbalance, LdLoss, DevNet
Fault, Dev Stop, Voltage, Aux
Sense
Last Trip #1
Phase A: 0.0
Range: 0.0 to 3200.0 A
Last Trip #1
Phase B: 0.0
Range: 0.0 to 3200.0 A
Last Trip #1
Phase C: 0.0
Range: 0.0 to 3200.0 A
Last Trip #1
GndAmps: 0.0
Range: 0.0 to 25.0 A
Last Trip #1
VOLTs: 220
Range: 0 to 9000 V
Last Trip #1
PowFact: 1.00
Range: 0.00 to 1.00
Last Trip #1
KW: 0.0
Range: 0.0 to 6553.5 kW
Last Trip #1
Avg Cur: 0.0
Range: 0.0 to 3200.0 A
Last Trip #1
%CurUnBl: 0
Range: 0 to 250%
