5–54 LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
DEVICENET OPERATIONS CHAPTER 5: COMMUNICATIONS
5.1.8 ACK Handler Object
The 'acknowledge handler object' manages the reception of message acknowledgments.
ACK handler Object, Class Code 0x2B, Services:
ACK handler Object, Class Code 0x2B, Attributes:
ACK handler Object, Class Code 0x2B, Instance 1:
USINT = 8-bit unsigned integer
UINT = 16-bit unsigned integer
5.1.9 Overload Object
The overload object allows the getting of the active parameter values.
Overload Object, Class Code 0x2C, Services:
Overload Object, Class Code 0x2C, Attributes:
7 Get Produced connection size UINT 0x0008
8 Get Consumed connection size UINT 0x0000
9 Get/Set Expected package rate UINT 0x00
12 Get/Set Watchdog timeout action UINT 0x00
13 Get Produced path length UINT 0x0006
14 Get Produced path BYTE [6] <null>
15 Get Consumed path length UINT 0x0004
16 Get Consumed path BYTE [6] <null>
17 Get Production inhibit timer UINT 0x0000
Attribute Access Name/Description Data Type Value
Code Name and Description of Services Available to this Object
0x0E Get_Attribute_Single: Returns the contents of the given attribute.
0x10 Set_Attribute_Single: Sets the contents of the given attribute
Attribute Access Name/Description Data Value
none --- --- --- ---
Attribute Access Name/Description Data Type Value
1 Get/Set Acknowledge Timer UINT 16
2 Get/Set Retry Limit USINT 1
3 Get COS Connection Instance UINT 4
Code Name and Description of Services Available to this Object
0x0E Get_Attribute_Single: Returns the contents of the given attribute.
Attribute Access Name/Description Data Value
none --- --- --- ---
