CHAPTER 5: COMMUNICATIONS DEVICENET OPERATIONS
LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 5–53
Connection Object, Class Code 5, Instance 2 (polled input/output connection):
Connection Object, Class Code 5, Instance 4 (COS/Cyc input/output connection):
4 Get Produced connection ID UINT MAC ID
5 Get Consumed connection ID UINT MAC ID
6 Get Initial comm. characteristics UINT 0x21
7 Get Produced connection size UINT 0x12
8 Get Consumed connection size UINT 0x12
9 Get/Set Expected package rate UINT 0x00
12 Get/Set Watchdog timeout action UINT 0x00
13 Get Produced path length UINT 0x0000
14 Get Produced path BYTE [6] <null>
15 Get Consumed path length UINT 0x0000
16 Get Consumed path BYTE [6] <null>
17 Get Production inhibit timer UINT 0x0000
Attribute Access Name/Description Data type Value
1GetState BYTE0x03
2GetInstance_type BYTE0x01
3 Get Export class trigger BYTE 0x80, 0x82
4 Get Produced connection ID UINT MAC ID
5 Get Consumed connection ID UINT MAC ID
6 Get Initial comm. characteristics UINT 0x01, 0xF1
7 Get Produced connection size UINT 0x01
8 Get Consumed connection size UINT 0x01
9 Get/Set Expected package rate UINT 0x00
12 Get/Set Watchdog timeout action UINT 0x00
13 Get Produced path length UINT 0x0006
14 Get Produced path BYTE [6]
*
*The Produced path will vary depending on the setting for Poll Data Group:
Poll Group 1: 0x20, 0x04, 0x24, 0x66, 0x30, 0x03 (Class 4, Inst. 102, Attr. 3)
Poll Group 2: 0x20, 0x04, 0x24, 0x67, 0x30, 0x03 (Class 4, Inst. 103, Attr. 3)
Poll Group 3: 0x20, 0x04, 0x24, 0x68, 0x30, 0x03 (Class 4, Inst. 104, Attr. 3)
Poll Group 4: 0x20, 0x04, 0x24, 0x69, 0x30, 0x03 (Class 4, Inst. 105, Attr. 3)
15 Get Consumed path length UINT 0x0006
16 Get Consumed path BYTE [6] 0x20, 0x04,
0x24, 0x64,
0x30, 0x03
17 Get Production inhibit timer UINT 0x0000
Attribute Access Name/Description Data Type Value
1GetState BYTE0x03
2GetInstance_type BYTE0x01
3 Get Export class trigger BYTE 0x00, 0x02,
0x10, 0x12
4 Get Produced connection ID UINT MAC ID
5 Get Consumed connection ID UINT MAC ID
6 Get Initial comm. characteristics UINT 0x01
Attribute Access Name/Description Data Type Value
