A–24 LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
LM10 AND ALLEN-BRADLEY SLC500 VIA DEVICENET™ CHAPTER A:
Refer to the DeviceNet Object Model of the LM10 relay for detail information on Class,
Instance, and Attribute.
Table A–7: Data to Get Motor Run Time
Address Data (hex) Description
N19:0 0101 TXID / Command
N19:1 0008 Port / Size
N19:2 0E09 Service / MAC ID (destination = 63)
N19:3 0064 Class
N19:4 0001 Instance
N19:5 0015 Attribute (Motor Run Time)
Table A–8: Data for Explicit Message Response, M1 Transferred to N20
Address Data (hex) Description
N20:0 0101 TXID / Command
N20:1 0002 Port / Size
N20:2 8E09 Service / MAC ID (Node = 09)
N20:3 Motor Run Time Value Service Response Data
