GE
Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
7-20 Section 7-7 - Network and Insite II Configuration
7-7-2 Insite II Configuration (cont’d)
8.) Change to Device Information
page, enter Device and Serial Number as the serial number of that
system, then press Modify Device Configurations
.
NOTE: The Device
name and Serial Number entered should be unique on server. It can be read from the rating
plate label.
Figure 7-20 Device_Information page
Figure 7-21 Rating plate label
To Next Page
