Functional checks
LOGIQ V3/V5/V5 Expert – Basic Service Manual 4-43
5726264-100 English Rev.8
4-3-33 Operator Panel Test
• The Operator Panel is tested when the LOGIQ V3/V5/V5
Expert is powered up as part of the start-up scripts, run at
every start-up.
For more info, please refer to ‘Diagnostics/Troubleshooting’
on page 7-1.
4-3-34 Peripheral checks
Check that peripherals work as described below:
4-3-34-1 Printer checks
The internal printer is controlled from the Print and Store keys
on the LOGIQ V3/V5/V5 Expert’s Operator Panel.
The factory default is:
• Print for the standard printer
Store for the screen capture to clipboard
4-3-35 Turn OFF Power to LOGIQ V3/V5/V5 Expert
See 4-2-3 ‘Power off’ on page 4-8 for more information.
4-3-36 Mechanical Functions Checks
4-3-36-1 Operator Panel Movement
Please refer to:
• 6-2 ‘LCD Monitor Adjustments’ on page 6-3
Table 4-3: Peripheral Checks
Step Task to do Expected Result(s)
1. Press FREEZE Stop image acquisition.
2. Press PRINT on the
Control Panel
The image displayed on the screen is
printed on B&W printer.
3. Connect with Foot
Switch on USB port
and press once.
To start image acquisition (the same
function as FREEZE key).
