Service Adjustments
6-8 LOGIQ V3/V5/V5 Expert – Basic Service Manual
5726264-100 English Rev.8
6-2-1-3-2 Adjust LCD Monitor by Software(continued)
• To adjust the Brightness: Press Set/B Pause to choose
the adjustment button, hold down the Set/B Pause key
and move the trackball to move the adjustment button.
Move the adjustment button to the left to decrease the
brightness or move the adjustment button to the right to
increase the brightness.
Figure 6-11. Brightness
3. Press Reset to return to the default setting; Press Exit to
exit the setting menu.
Figure 6-12. Reset
NOTE: Press Reset button and the three color temperature settings
will return to the default settings.
