GE LOGIQ V3 User Manual

Completing the setup
LOGIQ V3/V5/V5 Expert – Basic Service Manual 3-19
5726264-100 English Rev.8
3-5-6-1 Pin assignment for each connector
Table 3-6: Pin Assignments of External VGA
Pin No. Signal Pin No. Signal
1RED9NC
2 GREEN 10 NC
3BLUE11NC
4NC12NC
5NC13HSY
6 GND 14 VSY
7 GND 15 NC
8GND
Table 3-7: Pin Assignments of USB
Pin No. Signal Pin No. Signal
1 +5 VDC 5 +5 VDC
2DATA6DATA
3DATA7DATA
4GND8GND
Table 3-8: Pin Assignments of Audio
Pin No. Signal Pin No. Signal
1GND4NC
2L+5R+
3 Speaker L 6 Speaker R
Table 3-9: Pin Assignment of S-Video
Pin No. Output Signal Pin No. Output Signal
1GND 3Y
2GND 4C
Table 3-10: Pin Assignment of Composite Video Out
Pin No. Output Signal Pin No.
Output
Signal
1 Composite Out 2 GND

GE LOGIQ V3 Specifications

General

Brand	GE
Model	LOGIQ V3
Category	Medical Equipment
Language	English
