Revision B7-4
PCB Assemblies: 801212-003A CPU PCB Assembly
MAC 5000 ECG analysis system
2000657-002
28 3144-324 IC SM AMPL LM324 U7 1
29 3144-393 IC SM COMP LM393 U8, U21 2
30 400080-002 IC SM 1A DRVR H-BRIDGE L6201 U10 1
31 402085-001 CRYSTAL OSCILL SM 32.768 KHZ Y3 1
32 402821-001 IC SM AC 74AC257 U28, U29 2
33 403026-001 RES SM CER 3.3 5% 1/4W R57, R142, R204 3
34 403187-001 DIODE SM SCHOTTKY 1-AMP 40V CR5, CR6, CR23, CR25, CR26 5
35 403800-002 FERRITE BEAD SM BLM41P600SPT FB2, FB3, FB4, FB5, FB6, FB7, FB8, FB14, FB15,
FB18, FB20, FB21, FB22, FB23, FB24, FB27,
FB29, FB30, FB32
19
36 403907-001 CAP SM TANT 1.0UF 10% 35V C28, C31, C213 3
37 404327-001 DIODE ZENER SM BZX84C6V8L Z1, Z520 2
38 404579-015 CONN RCPT RA PC MT 15P 3 ROW J7 1
39 405585-001 CAP SM TANT 47UF 20% 10V C120 1
40 406884-013 CAP SM TANT 10UF 10% 35V C53, C101, C107, C116, C145 5
41 407461-026 HEADER 4-WALL RT ANGLE LP 26P J12 1
42 408880-001 DIODE SM RECT SHOTTKY 3A 40V CR3, CR4 2
43 410238-001 IC SM CMOS 14106 U9 1
44 410334-003 RES SM 0603 100 1% 1/16W R2, R4, R28, R29, R50, R56, R58, R60, R61,
R64, R70, R114, R178
13
45 410334-008 RES SM CER 0603 1K 1% 1/16W R10, R40, R43, R54, R76, R105, R123, R129,
R130, R164, R179, R180, R181, R185, R186,
R191, R192, R197, R215
19
46 410334-009 RES SM 0603 2K 1% 1/16W R53, R73, R74 3
47 410334-013 RES SM CER 0603 10K 1% 1/16W R6, R18, R44, R59, R71, R75, R84, R118,
R119, R120, R122, R124, R132, R134, R135,
R136, R137, R138, R139, R140, R141, R143,
R144, R146, R148, R151, R152, R153, R154,
R155, R156, R160, R168, R169, R170, R171,
R172, R175, R182, R195, R199, R200, R201,
R203, R214, R245
46
48 410334-019 RES SM 0603 100K 1% 1/16W R5, R21, R30, R31, R37, R38, R45, R46, R51,
R52, R62, R68, R85, R86, R87, R88, R173,
R176, R190, R193, R194, R210, R216
23
49 410334-031 RES SM 0603 10 OHM 1% 1/16W R158, R159 2
50 410334-034 RES SM 0603 511 OHM 1% 1/16W R16 1
Find
Num
Item Number Item Description Ref Des Qty
