GE Marquette MAC 5000

Revision B 7-5
PCB Assemblies: 801212-003A CPU PCB Assembly
MAC 5000 ECG analysis system
2000657-002
51 410334-038 RES SM 0603 80.6K 1% 1/16W R24, R26, R34 3
52 410334-040 RES SM 0603 49.9 OHM 1% 1/16W R157 1
53 410334-044 RES SM 0603 200 OHM 1% 1/16W R14, R15, R25, R49, R69, R77, R78, R117,
R125, R127, R150, R162, R196
13
54 410334-053 RES SM 0603 20.0K 1% 1/16W R19, R20, R23, R116, R211 5
55 410334-061 RES SM 0603 75 OHMS 1% 1/16W R65, R67, R82, R101, R102, R103, R104,
R110
8
56 410334-063 RES SM CER 0603 75K 1% R131, R147, R217 3
57 410334-066 RES SM CER 0603 4.99K 1% R9, R11, R145, R149, R174, R177, R198,
R213
8
58 410334-078 RES SM CER 0603 2.74K 1% R3 1
59 410334-120 RES SM 0603 1.0M 1% R202 1
60 410334-134 RES SM 0603 13.3K 1% 1/16W R35 1
61 410334-165 RES SM 0603 33.2K 1% 1/16 R22, R32, R33, R36, R39, R63, R66, R115 8
62 410345-009 CONN HDR RA MINIFIT W/PEGS 14P J11 1
63 411575-002 CAP SM X7R 0603 .1UF 10% BC1, BC2, BC3, BC4, BC5, BC6, BC7, BC8, BC9,
BC10, BC11, BC12, BC13, BC14, BC15, BC16,
BC17, BC18, BC19, BC20, BC21, BC22, BC23,
BC24, BC25, BC26, BC27, BC28, BC29, BC30,
BC31, BC32, BC33, BC34, BC35, BC36, BC37,
BC38, BC39, BC40, BC41, BC42, BC43, BC44,
BC45, BC46, BC47, BC48, BC49, BC50, BC51,
BC52, BC53, BC54, BC55, BC56, BC57, BC58,
BC59, BC60, BC61, BC62, BC63, BC64, BC65,
BC66, BC67, BC68, BC69, C5, C12, C23, C26,
C27, C35, C36, C37, C38, C44, C45, C46, C49,
C50, C57, C58, C61, C62, C65, C67, C72, C73,
C74, C75, C76, C77, C79, C93, C94, C96, C97,
C108, C111, C115, C119, C121, C124, C125,
C126, C128, C129, C130, C131, C138, C139,
C151, C152, C153, C154, C166, C167, C170,
C172, C173, C177, C184, C185, C190, C210,
C211, C216
130
64 411575-012 CAP SM X7R 0603 0.01UF 5% 50V C69, C106, C112, C113, C114, C127, C133,
C134, C135, C178, C187, C212
12
65 411576-001 CAP SM NPO 0603 12PF 5% 50V C159, C160 2
66 411576-008 CAP SM NPO 0603 47PF 5% 50V C900, C901, C902, C903, C904, C905, C906,
C907, C908, C909, C910, C911, C912, C913,
C914, C915, C916, C917, C918, C919, C920,
C921, C930, C931
24
Find
Num
Item Number Item Description Ref Des Qty
