Revision B7-6
PCB Assemblies: 801212-003A CPU PCB Assembly
MAC 5000 ECG analysis system
2000657-002
67 411576-009 CAP SM NPO 0603 150PF 5% C78, C85, C88, C122, C205 5
68 411576-018 CAP SM NPO 0603 470PF 5% 50V C1, C2, C3, C4, C6, C7, C8, C9, C10, C11, C14,
C16, C17, C18, C19, C20, C25, C29, C30, C34,
C39, C40, C41, C42, C43, C47, C48, C51, C52,
C55, C56, C59, C60, C63, C64, C66, C68, C70,
C71, C82, C83, C84, C95, C98, C100, C102,
C103, C105, C109, C117, C123, C147, C149,
C158, C162, C163, C164, C165, C168, C169,
C174, C176, C183, C191, C192, C196, C197,
C198, C202, C203, C204, C206, C207, C208
74
69 412010-001 SM RESONATOR 4MHZ TYPE KBR Y1, Y2, Y4, Y5 4
70 412110-001 CAP GOLD .22F 5.5V -20%/+80% C199 1
71 413134-001 XSTR DUAL MOSFET N-CH SI9945DY QP8, QP9 2
72 413233-001 XSTR SM DUAL NPN IMX1 QP2, QP3, QP4, QP5, QP6 5
73 414061-001 SM FERRITE BEAD 0603 BLM11A601 FB1, FB9, FB10, FB11, FB12, FB13, FB16, FB17,
FB19, FB28, FB31, FB36, FB37, FB38, FB39
15
74 415051-020 RES SM METAL WSL-2512 .020 1% R1, R184, R188 3
76 415800-001 INDUCTOR/XFMR SM CTX20-2 20UH L1 1
77 416171-001 FERRITE BEAD 0603 BLM11A12 FB33, FB34 2
78 417036-001 INDUCTOR SM 22UH L2, L3 2
79 417423-001 SMT IRDA COMPLIANT TRANCEIVER U11 1
80 417560-001 IC SM STRONG CPU SA-110 U32 1
81 417576-001 IC SM FPGA XC4013XL-2PQ208C U23 1
82 417577-001 IC SM PC87306 SUPER I/O U34 1
83 417876-001 IC SM FLAT PANEL CONT F65548A U35 1
84 417877-001 OSC W/EN SM 24.000 MHZ 3.3V OSC1 1
85 417880-001 IC SM REG MAX604 3.3V SO8 U27 1
86 417900-001 XFMR S, 2PRI/1SEC 10 PIN T2 1
87 417903-001 IC SM CMOS MUX/DEMUX U30 1
88 417909-001 IC MAX782 PS CNTRLR SSOP U39 1
89 417910-001 IC PWR DIST SWITCH TPS2010 U5 1
90 417913-001 IC RS485/422 XCVR MAX490 SO8 U22 1
91 417914-001 IC SM MAX213E +5V RS232 XCVR U3, U4 2
92 417946-001 CONN SM VERT FFC 1MM 26 POS J8, J13 2
Find
Num
Item Number Item Description Ref Des Qty
