Revision B 7-7
PCB Assemblies: 801212-003A CPU PCB Assembly
MAC 5000 ECG analysis system
2000657-002
93 417946-010 CONN SM VERT FFC 1MM 10 POS J4 1
94 417958-001 CONN HEADER 1MM SM VERT 31P J10 1
95 417967-001 NTC THERMISTOR 10K 5% @ 25C TEMP 1
96 419250-001 IC SM BATTERY CHGR LT1511 U2 1
97 419606-001 IC SM MOSFET SI4450DY N-CHAN Q8 1
98 419699-002 IC SM PWR SPLY MONMAX823 U41 1
99 419708-001 IC SM SERIAL E2 PROM X25128 U31 1
100 419787-001 CONN RCPT SM 0.8MM 10P J14 1
101 419955-001 SW REG +12V 1.5A PT78ST112H U26 1
102 419956-001 RES SM METAL WSL-2512 .100 1% R12, R13, R47 3
103 420999-003 HDR VERT .1 CTR W/LATCH 6P J2 1
104 421006-001 IC SM 8BIT 2PORT SW QSOP U14 1
105 421007-001 SOCKET SM SSFDC NAND CARD 3.3V J9 1
106 421081-001 IC SM I-SENSE AMP MAX472 U1 1
107 421082-001 CAP SM CERAMIC 10UF 50V C24 1
109 421123-001 FIRMWR DRAM LOGIC U37 1
110 421177-001 IC SM DRAM 1MX16 3.3V EDO U33, U36, U38 3
111 422056-001 IC SM TSSOP 74HC32 U15, U16, U17, U18, U19, U20 6
112 801213-001 CKT BD MAC 5000 CPU 1
113 SD801212-003 SCHEM 1212 BRD 0
114 421116-003 FIRMWR MAC 5000 SYS SUPVR V1A U6, U12, U13, U25 4
115 402414-001 TRANSISTOR SM FET NCHAN 2N7002 Q12, Q14 2
116 402414-001 CAP SMTANT 4.7UF 10% 50V C32, C33, C99, C140, C142, C171, C186, C194 8
117 411698-001 CAP SM TANT 47UF C148, C150, C200, C201 4
118 411907-001 RES SM CER 1.50 5% R212 1
119 412662-002 CAP SM TANT 220UF C132, C175, C181, C214 4
Find
Num
Item Number Item Description Ref Des Qty
