GE Monogram ZGU375NS Technical Service Guide

– 25 –
Views Description Part No. Qty
1 C SIMMER/ PORT RING ASSY WB32X10026 4
2 D SIMMER/ PORT RING ASSY WB32X10027 1
3 C BURNER BASE ASSY WB28X10044 4
4 D BURNERS BASE ASSY WB28X10045 1
5 C BURNER CAP, MATTE BLAC WB32X10028 4
6 D BURNER CAP, MATTE BLAC WB32X10029 1
7 VENTURI WB38X10062 5
8 JET HOLDER, MAIN,C,10.5K WB16X10013 2
9 JET HOLDER, MAIN, C, 12K WB16X10014 2
10 JET HOLDER, MAIN, C,9.9K WB16X10015 4
11 JET HOLDER, SIM,C&D,NAT WB16X10016 5
12 JET HOLDER, SIM,C&D,NAT WB16X10017 5
13 JET HOLDER, MAIN, D, 15K WB16X10018 1
14 JET HOLDER,MAIN,D,11.7K WB16X10019 1
15 ORIFICE-MAIN, NAT 15K WB21X10065 1
15 ORIFICE-MAIN, NAT 12K WB21X10066 2
15 ORIFICE-MAIN, NAT 10.5K WB21X10067 2
15 ORIFICE-MAIN, LP 11K WB21X10068 4
15 ORIFICE-MAIN, LP 9.9K WB21X10069 1
20 ORIFICE-SIMMER, NAT WB21X10070 5
20 ORIFICE-SIMMER, LP WB21X10071 5
22 VALVE,DUAL FLOW,C,NAT12O WB21X10057 3
23 VALVE,DUAL FLOW,C,NAT6O’ WB21X10058 2
24 VALVE,DUAL FLOW,C,LP.12O WB21X10059 3
25 VALVE,DUAL FLOW,C,LP.6O’ WB21X10060 2
26 VALVE BY-PASS NET - NAT WB21X10072 5
26 VALVE BY-PASS NET - LP WB21X10073 5
28 RE-IGNITER MODULE, 5 PT. WB13X10012 1
29 TRANSFORMER 120/230V WB27X10538 1
30 IGNITOR WB02X10794 5
31 CLIP, IGNITOR WB03X10146 5
32 ISPRING, IGNITOR WB02X10795 5
33 WIRE HARNESS, IGNITION WB18X10169 1
34 REGULATOR WB21X10064 1
35 POWER CORD WB18X10170 1
36 MANIFOLD WB02X10796 1
37 MANIFOLD TUBING - SET WB28X10046 1
38 SWITCH, IGNITER, @12 O’C WB24X10091 3
39 SWITCH, IGNITER, @ 6 O/C WB24X10092 2
40 KNOB, WITH CLIP WB03X10147 5
41 BEZEL WB07X10482 5
42 WIRE HARNESS, MAIN WB18X10171 1
43 HARNESS, LIGHTS WB18X10172 1
44 THUMB SCREW WB01X10153 2
45 FOAM TAPE WB01X10152 10
46 COOKTOP W/LOGO WB02X10797 1
47 PILOT LIGHT, 240V WB25X10008 5
50 LIGHT TUBE WB25X10009 5
51 GRATE, CENTER WB49X10075 1
52 GRATE, LEFT WB49X10071 1
53 GRATE, RIGHT WB49X10076 1
999 MINI MANUAL 31-20786 1
999 USE & CARE MANUAL 49-80023 1
999 INSTALLATION INSTRUCTION 49-80024 1
Note: The components listed below may differ from the components in your unit. Refer to the
microfiche or GEA IPC for the component and part number for your unit.
