– 6 –
Cooktop Features and Controls
Throughout this manual, features and appearances may vary from the customer’s model.
Ignition System
The surface burners are lit by electronic ignition,
eliminating the need for standing pilot lights with
constantly burning flames.
The ignition system consists of 5 spark switches
(1 on each valve), 5 spark electrodes (1 on each
burner), and a spark module.
WARNING: All 5 electrodes will spark when any
burner control knob is turned on. Do NOT
touch any of the burners when the igniters
are clicking.
The burners relight automatically if the flame goes
out. The burner control knob can be turned to any
position from HIGH to LO to light the burner. The
sparking will quit after the burner has been lit.
The burners may spark if a draft blows the flame
away from the burner sensor.
The ignition system is not sensitive to reversed
house wiring polarity.
Lighting a Burner
Push the control knob down and turn it counter-
clockwise to the desired position from HIGH to
SIM.
In case of a power outage, you can light the burn-
ers with a match. Hold a lit match to the burner,
then push in and turn the control knob to the de-
sired position. Use extreme caution when light-
ing burners this way.
Surface burners in use when an electrical power
failure occurs will continue to operate normally.
Feature Index
1 Dual-Flame Spillproof Burners—High Output
2 Dual-Flame Spillproof Burner—Maximum Output
3 Tactile-touch Control Knobs (One for Each Surface Burner)
4 Burner “ON” Indicator Lamps (One on Each Control Knob)
5 Interlocking Grates
6 Wok Ring Accessory
Design
information
(Not all features
are on all models.
Appearance may vary.)
1
5
1 43
1 1
2
6
