– 7 –
Burner Cleaning
The slits in the burner rings of the cooktop must
be kept clean at all times for an even, unhampered
flame.
The electrode of
the spark igniter is
behind each burner.
When one burner is
turned to “ON” to
light, all the burners
spark. Do not attempt to disassemble or clean
around any burner while another burner is
on. An electric shock may result, which could
cause you to knock over hot cookware.
Electrode
Note: Before removing the burner caps and
burner ring subassemblies, remember their size
and location. Replace them in the same location
after cleaning for proper burner operation.
High
Output
High
Output
High
Output
High
Output
Front of Cooktop
Maximum
Output
To completely clean the burner ring subassembly
remove the burner cap, head, and the 1-1/16 in.
nut. Lift off the burner ring. Do not remove the
burner bases.
Make sure the small holes in the simmer rings are
kept open. A sewing needle or wire twist-tie works
well to unclog them.
To remove burned-on food, soak the burner heads
Check to be sure the burner you turned on is
the one you want to use.
After the burner lights, turn the knob in
eitherdirection to adjust the flame size. To turn a
burner off, turn the knob clockwise as far as it will
go, to the OFF position.
The indicator lamp in the bezel for each knob
verifies the burner is ON.
Caution: Do not operate a burner for an extended
period of time without cookware on the grate. The
finish on the grate may chip without cookware to
absorb the heat.
Selecting Flame Size
All 5 burners on your cooktop have 2 rows of
flames. These dual-flame burners have an upper
ring of main burner ports which produce the main
flame for high-heat cooking from the HI knob
setting to the LO knob setting.
The bottom simmer flame is used for simmer
heat cooking operations such as melting choco-
late, holding food at serving temperature, and
simmering.
Both MAIN and SIMMER flames are lit when the
knob is between HI and LO. Only the simmer
flame is lit when the knob is in the SIMMER
position.
Burner Adjustment
There is no adjustment on this burner. See
Burner Cleaning.
