GE MULTILIN 269 MOTOR MANAGEMENT RELAY Series User Manual

3 SETUP AND USE Actual Values, Pg. 2
Page Line Information Line Description
3-8
2 1
PAGE 2: ACTUAL VALUESPAGE 2: ACTUAL VALUES
RTD TEMPERATURE DATARTD TEMPERATURE DATA
ACTUAL VALUES page 2 header.
(see note at end of Actual Values page 2).
2
NO RTDs ARE CONNECTEDNO RTDs ARE CONNECTED
TO THE 269TO THE 269
This line is shown only if the answer to the
question “ARE THERE ANY RTDs
CONNECTED?” is “NO”. This setpoint is lo-
cated on page 2 of Setpoints, line 3.
3 •
HOTTEST STATOR RTDHOTTEST STATOR RTD
RTD # X = XXX CRTD # X = XXX C
Maximum stator RTD temperature.
4 •
STATOR TEMPERATURESTATOR TEMPERATURE
RTD #1= XXX DEGREES CRTD #1= XXX DEGREES C
or
RTD TEMPERATURERTD TEMPERATURE
RTD #1= XXX DEGREES CRTD #1= XXX DEGREES C
RTD #1 temperature.
5 •
STATOR TEMPERATURESTATOR TEMPERATURE
RTD #2= XXX DEGREES CRTD #2= XXX DEGREES C
or
RTD TEMPERATURERTD TEMPERATURE
RTD #2= XXX DEGREES CRTD #2= XXX DEGREES C
RTD #2 temperature.
6 •
STATOR TEMPERATURESTATOR TEMPERATURE
RTD #3= XXX DEGREES CRTD #3= XXX DEGREES C
or
RTD TEMPERATURERTD TEMPERATURE
RTD #3= XXX DEGREES CRTD #3= XXX DEGREES C
RTD #3 temperature.
7 •
STATOR TEMPERATURESTATOR TEMPERATURE
RTD #4= XXX DEGREES CRTD #4= XXX DEGREES C
or
RTD TEMPERATURERTD TEMPERATURE
RTD #4= XXX DEGREES CRTD #4= XXX DEGREES C
RTD #4 temperature.
8 •
STATOR TEMPERATURESTATOR TEMPERATURE
RTD #5= XXX DEGREES CRTD #5= XXX DEGREES C
or
RTD TEMPERATURERTD TEMPERATURE
RTD #5= XXX DEGREES CRTD #5= XXX DEGREES C
RTD #5 temperature.
9 •
STATOR TEMPERATURESTATOR TEMPERATURE
RTD #6= XXX DEGREES CRTD #6= XXX DEGREES C
or
RTD TEMPERATURERTD TEMPERATURE
RTD #6= XXX DEGREES CRTD #6= XXX DEGREES C
RTD #6 temperature.
10 •
RTD TEMPERATURERTD TEMPERATURE
RTD #7= XXX DEGREES CRTD #7= XXX DEGREES C
RTD #7 temperature.
