GE MULTILIN 269 MOTOR MANAGEMENT RELAY Series User Manual

3 SETUP AND USE Actual Values, Pg. 3
Page Line Information Line Description
3-10
3 1
PAGE 3: ACTUAL VALUESPAGE 3: ACTUAL VALUES
MOTOR CAPACITY DATAMOTOR CAPACITY DATA
ACTUAL VALUES page 3 header.
2
ESTIMATED TIME TOESTIMATED TIME TO
TRIP = XXX SECONDSTRIP = XXX SECONDS
Estimated time to overload trip under present
conditions (seen only during overloads).
3
MOTOR LOAD AS A PERCENTMOTOR LOAD AS A PERCENT
FULL LOAD = XXX PERCENTFULL LOAD = XXX PERCENT
Actual motor current as a percentage of full
load.
4
THERMAL CAPACITYTHERMAL CAPACITY
USED = XXX PERCENTUSED = XXX PERCENT
Percentage of motor thermal capacity used.
5
END OF PAGE THREEEND OF PAGE THREE
ACTUAL VALUESACTUAL VALUES
Last line of page 3.
