3 SETUP AND USE Actual Values, Pg. 5
Page Line Information Line Description
3-12
5 1
PAGE 5: ACTUAL VALUESPAGE 5: ACTUAL VALUES
PRE-TRIP DATAPRE-TRIP DATA
ACTUAL VALUES page 5 header.
2
XXXXXXXXXXXXXXXXXXXXXX
This message is only displayed, and defaulted
to, when a trip or alarm occurs and describes
the trip/alarm condition. Refer to Table 3-4
Trip/Alarm Messages and Fault Diagnosis. See
section 3.3c.
3
CAUSE OF LAST EVENT:CAUSE OF LAST EVENT:
XXXXXXXXXXXX XXXXXXXXXXXX
This message describes the cause of the last
event detected by the 269. See section 3.3d. It
will be updated when an event occurs (trip or
inhibit).
4
CAUSE OF LAST TRIP:CAUSE OF LAST TRIP:
XXXXXXXXXXXX XXXXXXXXXXXX
This message describes the cause of the last
trip. It will be updated when a trip occurs. See
section 3.3c.
5
PRE-TRIP AVERAGE MOTORPRE-TRIP AVERAGE MOTOR
CURRENT = XXXXX AMPSCURRENT = XXXXX AMPS
Average motor phase current prior to last relay
trip.
6
PRE-TRIP PHASE CURRENTPRE-TRIP PHASE CURRENT
I1 = XXX AMPSI1 = XXX AMPS
I1 motor phase current prior to last relay trip.
7
PRE-TRIP PHASE CURRENTPRE-TRIP PHASE CURRENT
I2 = XXX AMPSI2 = XXX AMPS
I2 motor phase current prior to last relay trip.
8
PRE-TRIP PHASE CURRENTPRE-TRIP PHASE CURRENT
I3 = XXX AMPSI3 = XXX AMPS
I3 motor phase current prior to last relay trip.
9
PRE-TRIP U/B RATIOPRE-TRIP U/B RATIO
(In/Ip) XXX PERCENT(In/Ip) XXX PERCENT
Ratio of negative to positive sequence currents
prior to last relay trip.
10
PRE-TRIP G/F CURRENTPRE-TRIP G/F CURRENT
G/F = XXX AMPSG/F = XXX AMPS
Ground fault current prior to last relay trip.
("=" will be ">" if delay set to 0.0, 0.25, 0.5)
11
PRE-TRIP MAX STATOR RTDPRE-TRIP MAX STATOR RTD
RTD # X = XXX C RTD # X = XXX C
Maximum stator RTD temperature prior to last
relay trip. This message is display only if the
answer to the question “ARE THERE ANY
RTDs CONNECTED?” is “YES”. This setpoint
is located on page 2 of Setpoints, line 3.
12 •
PRE-TRIP AVERAGE VOLTAGEPRE-TRIP AVERAGE VOLTAGE
VOLTS = XXXXXVOLTS = XXXXX
Average voltage prior to last relay trip
13 •
PRE-TRIP KWATTSPRE-TRIP KWATTS
KW = +XXXXXKW = +XXXXX
Positive or negative kwatts prior to last relay
trip. (See Figure 3.8 for Power Measurement
Conventions.)
14 •
PRE-TRIP KVARSPRE-TRIP KVARS
KVAR = +XXXXXKVAR = +XXXXX
Positive or negative kvars prior to last relay
trip. (See Figure 3.7 for Power Measurement
Conventions.)
15 •
PRE-TRIP POWER FACTORPRE-TRIP POWER FACTOR
PF = X.XX LAGPF = X.XX LAG
Power factor prior to last relay trip. The lead or
lag word messages are also captured and dis-
played prior to last relay trip.
16 •
PRE-TRIP FREQUENCYPRE-TRIP FREQUENCY
HZ = XX.XHZ = XX.X
Frequency prior to last relay trip
