74 GE INFORMATION G500 SUBSTATION GATEWAY INSTRUCTION MANUAL
CHAPTER 6: SPECIFICATIONS
Electrical
Environmental specifications
Temperature and Humidity
Relative Humidity for operation is up to 95%, non condensing. Ambient temperature values
for the product:
* if PCIe Cards are installed the operating temperature of the system is reduced to 60°C. If
non-compliant PCIe Cards are used the user has to take care of proper operation of the
plug-in card and the operating temperature of the System may be decreased.
Time synchronization Precision Time Protocol
Can be configured for IEEE 1588 PTP, IRIG-B or NTP
IRIG-B Input Connector
Available as 3 positions removable Phoenix terminal block on rear of the unit
IRIG-B Output Connector
Can be configured to be derived from IEEE 1588, IRIG-B input or NTP, or free
run system clock.
Video Output DisplayPort (DP)
2x DP++ (Dual-mode DisplayPort) with Multi Stream Transport (MST),
available on the rear of the chassis.
Each DP++ supports up to two multi-stream Dell P2415Q monitor or similar
displays (Windows only).
Resolution:
Up to UHD (4k, 3840x2160) for single displays connected to each port
Up to QHD (2560x1440) for multi-stream connected displays.
Audio Output 3.5 mm audio jack for substation alarms
Built in high (+90dB) pitch audio buzzer
USB Ports 2x USB 3.0 Type A (male) on front of the unit
4x USB 2.0 Type A (male) on rear of the unit
1x USB 2.0 Type A internal - for software license keys
SD Card SD, SDHC and SDXC SD-Cards according to Version 1.0, Version 2.0 and
Version 3.0 (Windows only).
Maximum SDXC size 64GB.
SD card slot accessible on front of the unit, uses push-pull mechanism.
Maintenance Ports Console port
1x USB 2.0 Type B port on front of chassis connected to internal USB to
Serial bridge, allows access to Console for debug.
Local Ethernet
100/1000BASE-T maintenance Ethernet port accessible via front of the unit,
separate from 6 Ethernet ports on the back.
Power Supply Dual/ Redundant hot-swappable power supplies
each with individual removable Phoenix 1942293 terminal block
Low Voltage power supply: 20-54VDC Nominal ±10%, 10.2A Max
High Voltage power supply: 100-300VDC Nominal +10%/-12%, 1.8A Max
100-240VAC Nominal ±10%, 2.1A Max
NOTE: To meet 61850-3 compliance, LV power supply must be supplied by 48V
nominal to meet 50ms hold up time.
Operation Condition
Storage -40°C to 85°C
Operation 2 core -40°C to 70°C
Operation 4 core -40°C to 60°C
Operation with PCIe Cards installed * -40°C to 60°C
