5-12 F650 Digital Bay Controller GE Multilin
5.2 PRODUCT SETUP 5 SETPOINTS
5
5.2.6 DEMAND
5.2.6.1 METERING VALUES AND SETPOINTS FOR THE DEMAND
The demand calculation is made according to the following primary parameters:
Table 5–14: PRIMARY DEMAND VALUES
Different integration methods can be selected to calculate current and power values.
Calculated demand values are as follows:
Table 5–15: DEMAND CALCULATED VALUES
Demand module setpoints are as follows:
Table 5–16: DEMAND SETPOINTS
PRIMARY DEMAND VALUES STEP
IA (RMS) KA
IB (RMS) KA
IC (RMS) KA
IG (RMS) KA
ISG (RMS) KA
I2 KA
Three phase active power (W) MW
Three phase reactive power (VAR) MVAr
Apparent power (VA) MVA
DEMAND CALCULATED VALUES
DEMAND IA DEMAND IG DEMAND W
DEMAND IA MAX DEMAND IG MAX DEMAND W MAX
DEMAND IA DATE DEMAND IG DATE DEMAND W DATE
DEMAND IB DEMAND ISG DEMAND VAR PWR
DEMAND IB MAX DEMAND ISG MAX DEMAND VAR MAX
DEMAND IB DATE DEMAND ISG DATE DEMAND VAR DATE
DEMAND IC DEMAND I2 DEMAND VA PWR
DEMAND IC MAX DEMAND I2 MAX DEMAND VA MAX
DEMAND IC DATE DEMAND I2 DATE DEMAND VA DATE
SETPOINT > PRODUCT SETUP > DEMAND
setpoint Description Name Default Value Step Range
Function permission Demand Function DISABLED N/A [DISABLED – ENABLED]
Demand method for current values CRNT Demand Method THERMAL EXPONENTIAL N/A [BLOCK INTERVAL -
ROLLING DEMAND -
THERMAL EXPONENTIAL]
Demand method for Power values POWER Demand Method THERMAL EXPONENTIAL N/A [BLOCK INTERVAL -
ROLLING DEMAND -
THERMAL EXPONENTIAL]
Demand interval Demand Interval 5 Minutes N/A [5 – 10 – 15 – 20– 30–60]
Trigger Enabled Trigger Enabled DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
