GE Multilin F650 Digital Bay Controller 5-23
5 SETPOINTS 5.3 SYSTEM SETUP
5
The signals associated to breaker maintenance can be
monitored at “Actual > Metering > Records Status >
Breaker Maintenance”, and they are as follows:
Table 5–24: BREAKER MAINTENANCE STATUS
5.3.4 SWITCHGEAR
In firmware release 1.70 and higher ones there is the
possibility to enable or disable the generation of internal
signals for the different units (protection, control, inputs and
outputs, switchgear) available in the device.
The configuration of snapshot events for each switchgear
(enable or disable) can be selected at setpoints> System
Setup > Switchgear.
Table 5–25: SWITCHGEAR SETPOINTS
BREAKER MAINTENANCE DESCRIPTION
KI2t PHASE A ALARM This signal activates when the set value for phase A is exceeded.
KI2t PHASE B ALARM This signal activates when the set value for phase B is exceeded.
KI2t PHASE C ALARM This signal activates when the set value for phase C is exceeded.
BKR OPENINGS ALARM Relay total Number of Openings alarm
BKR OPEN 1 HOUR ALRM Relay total Number of Openings in one hour alarm
RESET KI2t COUNTERS KI2t Counters reset signal. This signal is configured at Setpoint > Relay Configuration > Protection
Elements, and it is used for resetpoint the KI2t counter through the corresponding signal, command,
digital input, etc.
RESET BKR COUNTERS Reset signal for the Opening and Closing Counters. This signal is configured at Setpoint > Relay
Configuration > Protection Elements, and it is used for resetpoint the breaker Opening and closing
counters.
BREAKER OPENINGS Number of Breaker openings
BREAKER CLOSINGS Number of Breaker closings
KI2t PHASE A Accumulated KI2t value for phase A ( KI2t Counter for Phase A)
KI2t PHASE B Accumulated KI2t value for phase B ( KI2t Counter for Phase B)
KI2t PHASE C Accumulated KI2t value for phase C ( KI2t Counter for Phase C)
BKR OPENING TIME Maximum breaker Opening time. This signal is configured at Setpoint > Relay Configuration
>Switchgear in the number of switchgear corresponding to the breaker selection
BKR CLOSING TIME Maximum breaker Closing time. This signal is configured at Setpoint > Relay Configuration
>Switchgear in the number of switchgear corresponding to the breaker selection
SETPOINT > SYSTEM SETUP > SWITCHGEAR
setpoint Description Name Default
Value
Step Range
Snapshot Event generation for switchgear #1 Snapshot Events SWGR 1 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #2 Snapshot Events SWGR 2 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #3 Snapshot Events SWGR 3 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #4 Snapshot Events SWGR 4 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #5 Snapshot Events SWGR 5 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #6 Snapshot Events SWGR 6 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #7 Snapshot Events SWGR 7 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #8 Snapshot Events SWGR 8 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #9 Snapshot Events SWGR 9 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #10 Snapshot Events SWGR 10 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #11 Snapshot Events SWGR 11 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #12 Snapshot Events SWGR 12 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #13 Snapshot Events SWGR 13 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #14 Snapshot Events SWGR 14 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #15 Snapshot Events SWGR 15 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #16 Snapshot Events SWGR 16 DISABLED N/A [DISABLED – ENABLED]
