4-18 F650 Digital Bay Controller GE Multilin
4.1 ENERVISTA 650 SETUP SOFTWARE INTERFACE 4 HUMAN INTERFACES
4
4.1.7 SETTINGS MENU OVERVIEW
Table 4–5: GENERAL OVERVIEW OF SETPOINT MENU IN ENERVISTA 650 SETUP:
Options enabled only in On-line mode are marked as (*). Options enabled only in Off-line mode are marked as (**)
4.1.7.1 PRODUCT SETUP
Table 4–6: GENERAL OVERVIEW OF PRODUCT SETUP MENU:
Options enabled only in On-line mode are marked as (*). Options enabled only in Off-line mode are marked as (**)
SETPOINT
Product Setup
Communications settings for all protocols and physical mediums.
ModBus user map definition, fault report, oscillography, data logger and
demand settings.
System Setup
General Settings, Flex Curves Definition, Breaker settings and
maintenance, and switchgear snapshot events management.
Protection Elements
Phase, Neutral, Ground, Sensitive Ground and Negative Sequence
Current Settings. Voltage Elements settings and Power Settings
management.
Control Elements
Setting groups, under and overfrequency settings, synchrocheck,
autoreclose, breaker failure, VT fuse failure, broken conductor and
locked rotor settings management.
Inputs/Outputs Contact I/O settings for all boards available in device, Remote Comms.
Relay Configuration
Configuration of Outputs, LEDs, Operations, Protection Elements,
Oscillography, Operations, Control Events, Switchgear, Inputs, Virtual
Inputs, Operations and HMI. Whole relay configuration with internal relay
signals or user-definable ones as logic (virtual outputs).
Logic Configuration
Logic configuration graphic editor (PLC Editor). It is a PLC Project file
editor that contains all the internal drawings used to make the logic
(virtual outputs) based on IEC 61131-3 standard. Functional block
diagram (FDB).
Clock (*)
Relay synchronization to computer clock or to user-definable date and
time. On-line mode only.
PRODUCT
SETUP
Communication
Settings
Serial Ports, Network (Ethernet), ModBus Protocol, DNP Slave and IEC
870-5-104 settings.
ModBus User Map
ModBus user map definition. The ModBus user map is formed by 256
records, selectable from the complete relay ModBus map.
Fault Report Fault report settings. Possibility to show fault reports on HMI screen.
Oscillography
Oscillography settings (trigger position, samples per cycle, etc). The
trigger and digital channels (up to 16) must be configured in
“Settings>Relay configuration”.
Data Logger Data logger configuration
Demand
Demand settings. The demand trigger and demand reset signals must be
configured in “Settings>Relay configuration”
