2.2 SUMMARY 2 PRODUCT DESCRIPTION
2
2.2SUMMARY
2.2.1 ANSI DEVICE NUMBERS AND FUNCTIONS
Table 2–1: OTHER DEVICE FUNCTIONS
DEVICE
NUMBER
FUNCTION DEVICE
NUMBER
FUNCTION
25 Synchronism 51PV Phase Time Overcurrent with Voltage
Restraint (two elements, High and Low)
27P Phase Undervoltage 51SG Ground Time Overcurrent for sensitive
ground systems (measured from 5
th
current transformer)
27X Auxiliary Undervoltage 59N Neutral Overvoltage (two elements, High
and Low)
32 Sensitive Directional Power 59P Phase Overvoltage
32FP Forward Power 59X Auxiliary Overvoltage
46 Negative Sequence Time Overcurrent 67P Phase Directional
47 Negative Sequence Overvoltage 67N Neutral directional
48 Locked Rotor 67G Ground Directional
49 Protection against Overload by thermal model 67SG Sensitive Ground Directional
50G Ground Instantaneous Overcurrent (measured
from 4
th
current transformer)
79 Automatic Recloser (Four shot recloser)
50N Neutral Instantaneous Overcurrent (calculated
from the phase currents)
810 Overfrequency
50P Phase Instantaneous Overcurrent (two
elements, High and Low)
81U Underfrequency
50SG Ground Instantaneous Overcurrent for
sensitive ground systems (measured from 5
th
current transformer)
I2/I1 Broken Conductor
50ISG Isolated Ground Instantaneous Overcurrent
(measured from 5
th
current transformer)
50BF Breaker Failure
51G Ground Time Overcurrent (measured from 4
th
current transformer)
VTFF VT Fuse Failure
51N Neutral Time Overcurrent (calculated from the
phase currents)
INPUTS/OUTPUTS METERING COMMUNICATIONS
9 Analog Inputs: 5 current inputs (3 for
phases, 1 for ground, 1 for sensitive
ground), 4 voltage inputs (3 for phases, 1
for busbar or auxiliary voltage)
Metering Current for phases, ground
and sensitive ground inputs
Front RS232 port, Two rear
RS485/fibre optic ports, 10/100 TX
and 100 FX Mbps Ethernet port
Digital Programmable Contact Inputs (up
to 32)
Voltages phase to phase and phase
to ground
ModBus Communications RTU
and over TCP/IP
Digital Programmable Contact Outputs
(up to 16)
Real, Reactive and Apparent Power
and Power Factor
DNP Multimaster (3.0 Level 2)
32 Latched Virtual Inputs
32 Self-Reset Virtual Inputs
Three Phase Energy IEC 870-5-104
Virtual Outputs (up to 512) Frequency ModBus User Map
Tripping and closing circuit supervision Sequence components of currents
and voltages
