GE Multilin GEK-113000T User Manual

2-26 F650 Digital Bay Controller GE Multilin
2.5 EXTERNAL CONNECTIONS 2 PRODUCT DESCRIPTION
2
2.5EXTERNAL CONNECTIONS
F650 units can hold two different options for F module:
Option 1:Board with 16 inputs and 8 outputs.
Option 2: Board with 8 digital inputs, 4 circuit supervision outputs, 6 conventional outputs, and two current sensing outputs
Each model has a different wiring diagram, as follows:
Figure 2–2: WIRING DIAGRAM FOR MODELS WITH OPTION 1 (189C4216H3)

GE Multilin GEK-113000T Specifications

General

Brand	GE
Model	Multilin GEK-113000T
Category	Controller
Language	English
