GE Multilin F650 Digital Bay Controller 3-7
3 HARDWARE 3.2 MECHANICAL DESCRIPTION
3
Figure 3–7: COMMUNICATIONS MEDIA SELECTOR GUIDE
Communication boards are installed at the rear part of the unit, the upper port being reserved for the
asynchronous communications board and CAN, and the lower port for the ETHERNET board in any of its
configurations.
Skilled personnel must carry out the insertion or extraction of communication boards only after interrupting the
relay auxiliary voltage.
TYPE OF COMMUNICATION CONNECTOR
RS485
Plug-in, 3 poles.
IRIG B Plug-in, 2 poles.
Plastic fiber optic Versatile Link
Ethernet 10/100 UTP (10/
100BaseTX)
RJ45, Class 5.
Glass fiber optic (100BaseFX) ST
Ethernet 100 FX (100BaseFX) ST
CAN Distributed I/O ST
