10–6 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
VLAN CHAPTER 10: VLAN
Example 10-1: Adding three VLANs
ML2400#
set vlan type=port
VLAN set to Port-based.
ML2400# vlan type=port
ML2400(port-vlan)##
add id=10 name=engineering port=14
Vlan added successfully with
Vlan id : 10
Vlan name : engineering
Ports : 14
ML2400(port-vlan)## add id=20 name=engineering port=14
ERROR - Duplicate Vlan name
ML2400(port-vlan)## add id=20 name=sales port=14
Vlan added successfully with
Vlan id : 20
Vlan name : sales
Ports : 14
ML2400(port-vlan)## add id=30 name=marketing port=14
Vlan added successfully with
Vlan id : 30
Vlan name : marketing
Ports : 14
(continued on next page)
Each VLAN requires a unique name.
Here, VLAN 10 and 20 had the same
name
