SLOW COMMUNICATOR FORMAT CODES
20
NX-4V2 Control
46 AUXILIARY OUTPUT 1 - 2 SPECIAL TIMING 2 ............ feature select
Location 46 contains special timing feature activation for the four auxiliary outputs. Segment 1 corresponds to output 1; Segment 2
corresponds to output 2.
Segments 1 - 2:
1 = On if output should be timed in minutes; Off if timed in seconds.
2 = On if output should latch; Off if output should be timed.
3 = On if output should stop timing upon code entry; Off if the output should continue to time upon code entry.
4 = On if output should only activate between the closing and opening time in loc. 52 and 53.
5 = On if output should only activate between the opening and closing time in loc. 52 and 53.
6 = On if output should be inverted (0 volts going to 12 volts when activated).
7 = Reserved.
8 = Reserved.
47 AUXILIARY OUTPUT 1, EVENT & TIME 2 ............ numerical
Segment 1: Use Table XIII-1 to select the event that will activate Auxiliary Output 1.
Segment 2: Program the timing from 0-255 (minutes or seconds, depending on data programmed in Segment 1, Location 46).
Programming a "0" makes the output follow the event.
48 AUXILIARY OUTPUT 2, EVENT & TIME 2 ............ numerical
Segment 1: Use Table XIII-1 to select the event that will activate Auxiliary Output 2.
Segment 2: Program the timing from 0-255 (minutes or seconds, depending on data programmed in Segment 2, Location 46).
Programming a "0" makes the output follow the event.
49 - 50 RESERVED
Table XIII-1 AUXILIARY OUTPUT EVENT SELECTION
DATA EVENT DATA EVENT DATA EVENT
0
/
Burglary Alarm 19 Exit 38 Download In Process
1
/ Fire Alarm 20 Entry or Exit 39 Smoke Power
2
/ 24 Hour Alarm 21 Armed State 40 Short Circuit (Over-current)
3
/ Trouble Alarm 22 Disarmed State 41 Box Tamper
4
/ Tamper Alarm 23 Ready 42 Siren Tamper
5 Yelping Siren (Burglary) 24 Not Ready 43 Any Open
6 Temporal Siren (Fire) 25 Fire 44 Any Short
7 Any Siren 26 Fire Trouble 45 Any Fault (Open/ Short on Non-Fire Zone)
8 Any Bypass 27 Chime 46
/ Any Alarm
9 AC Fail 28
/ Expander Trouble 47 Beeping Keypad
10 Low Battery 29 Dynamic Battery Test Time 48
/ Code Entry (See note below)
11
/ Duress 30 Open Period 49
˜ /
Key FOB Function 1
12
/ Aux 1 Keypad Zone 31 Closed Period 50
˜ /
Key FOB Function 2
13
/ Aux 2 Keypad Zone 32 Listen-In 51 Always ON
14
/ Panic Keypad Zone 33 Line Seizure 52 Alarm Flash
15 Keypad Tamper 34 Ground Start 53 Armed Away
16
/ Autotest 35 Fail To Communicate 54 Armed Stay
17 Alarm Memory 36 Telephone Line Fault 55 Aux Comm Fail
18 Entry 37 Program Mode 56 (CP-01) Progress Annunciation
˜ Events 49 & 50 require one or more of the following to operate: NX-408E, NX-416E, NX-448E wireless receivers, or NX-1700E card reader
/ If set to follow condition, these events will be 1 second.
Note: When Event 48 is programmed, it is possible to program a user code's authorization to select which output(s) a particular code will activate.
When LED 8 is on for an authorization, then LEDs 1- 2 correspond to that code activating outputs 1 - 2 respectively. (See programming the
LED keypads on page 7.)
L 51 AUTOTEST CONTROL 4 ............ numerical
Segment 1: Program a "1" if the interval is to be in hours; Program a "0" if in days. Add a A2" to suppress the daily test or a A3" to
suppress the hourly test if any report has been sent.
Segment 2: Program the Autotest interval from 1-255 hours/days.
Segment 3: Program the Autotest report hour in 24-hour format (if the interval is in hours, this segment is ignored).
Segment 4: Program the Autotest report time, number of minutes after the hour.
