NX-4V2 Control
LOCATIONS 56- 83 ARE ONLY USED WHEN REPORTING EVENTS TO A PAGER OR USING A SLOW FORMAT SUCH AS
4+2. When using Contact ID or SIA, there is no need to program these locations.
The digit programmed in each of the following locations will be sent as the upper HEX digit in place of the alarm event code. The zone
ID or user ID will always be reported as the lower HEX digit (1-F). For example, if the zone ID or user ID is 3, the 4+2 lower digit will be
“3”. See Appendix 4 on page 41. If the segment is left as “0” and the feature is enabled in Location 23, the NX-4V2 will report “A”.
56 RESTORE COMMUNICATOR CODE 1 ............ numerical
Location 56 contains the event code for any zone "Restore" for a 4+2 format. (Box on pg 22.)
57 BYPASS COMMUNICATOR CODE 1 ............ numerical
Location 57 contains the event code for a zone "Bypass" for a 4+2 format. (Box on pg 22.)
58 TAMPER COMMUNICATOR CODE 1 ............ numerical
Location 58 contains the event code for a zone "Tamper" for a 4+2 format. (Box on pg 22.)
59 TROUBLE COMMUNICATOR CODE 1 ............ numerical
Location 59 contains the event code for a zone "Trouble" for a 4+2 format. (Box on pg 22.)
60 SENSOR LOW BATTERY COMMUNICATOR CODE 1 ............ numerical
Location 60 contains the event code for a zone "Sensor Low Battery" for a 4+2 format. (Box on pg 22.)
61 SENSOR MISSING COMMUNICATOR CODE 1 ............ numerical
Location 61 contains the event code for a zone "Sensor Missing" for a 4+2 format. (Box on pg 22.)
62 DURESS COMMUNICATOR CODE 2 ............ numerical
Location 62 contains the digits that will be sent for a 4+2 format if the “Duress” code is enabled in location 44. (Box on pg 22.)
63 KEYPAD AUXILIARY 1 COMMUNICATOR CODE 2 ............ numerical
Location 63 contains the digits that will be sent for a 4+2 format if the keypad "Auxiliary 1" (Fire) is enabled in loc 23. (Box on pg 22.)
64 KEYPAD AUXILIARY 2 COMMUNICATOR CODE 2 ............ numerical
Location 64 contains the digits that will be sent for a 4+2 format if the keypad "Auxiliary 2" (Medical) is enabled in location 23. (Box on
pg 22.)
65 KEYPAD PANIC COMMUNICATOR CODE 2 ............ numerical
Location 65 contains the digits that will be sent for a 4+2 format if the keypad "Panic" is enabled in location 23. (Box on pg 22.)
66 KEYPAD MULTIPLE CODE ENTRY TAMPER COMM CODE 2 ............ numerical
Location 66 contains the digits that will be sent for a 4+2 format if the keypad "Multiple Code Entry" (Tamper) is enabled in location 23.
(Box on pg 22.)
67 BOX TAMPER / RESTORE COMMUNICATOR CODE 4 ............ numerical
Location 67 contains the digits that will be sent for a 4+2 format if the "Box Tamper" feature is enabled in location 37. Segments 1 & 2
contain the digits of the "Box Tamper". Segments 3 & 4 contain the digits of the "Box Tamper Restore". (Box on pg 22.)
68 AC FAIL / RESTORE COMMUNICATOR CODE 4 ............ numerical
Location 68 contains the digits for a 4+2 format that will be sent if "AC Fail Reporting" is enabled. Segments 1 & 2 contain the digits of
the "AC Fail". Segments 3 & 4 contain the digits of the "AC Fail Restore". (Box on pg 22.)
69 LOW BATTERY / RESTORE COMMUNICATOR CODE 4 ............ numerical
Location 69 contains the digits for a 4+2 format that will be sent if "Low Battery Reporting" is enabled. Segments 1 & 2 contain the
digits of the "Low Battery Reporting". Segments 3 & 4 contain the digits of the "Low Battery Restore". (Box on pg 22.)
70 AUX POWER OVERCURRENT / RESTORE COMM CODE 4 ............ numerical
Location 70 contains the digits for a 4+2 format that will be sent if "Aux Power Overcurrent Reporting" is enabled. Segments 1 & 2
contain the digits of the "Aux Power Overcurrent Reporting". Segments 3 & 4 contain the digits of the "Aux Power Overcurrent
Restore". (Box on pg 22.)
71 BELL TAMPER / RESTORE COMMUNICATOR CODE 4 ............ numerical
Location 71 contains the digits for a 4+2 format that will be sent if siren supervision reporting is enabled. Segments 1 & 2 contain the
digits of the "Bell Tamper Reporting". Segments 3 & 4 contain the digits of the "Bell Tamper Restore". (Box on pg 22.)
72 TELEPHONE LINE CUT / RESTORE COMM CODE 4 ............ numerical
Location 72 contains the digits for a 4+2 format that will be sent if "Telephone Line Cut Reporting" is enabled. Segments 1 & 2 contain
the digits of the "Telephone Line Cut Reporting". Segments 3 & 4 contain the digits of the "Telephone Line Cut Restore". (Box on pg
22.)
73 RESERVED
