110 73 CONFIGURATION GROUP 1 ALARM CODE
4
CONFIGURATION GROUP 1 CHARACTERISTIC SELECT
Segment 1 (Circle Numbers To Program)
1 Fire (enable for fire zone) 5 Delay 1 zone (enable to follow Timer 1 Entry/Exit times)
2 24 Hour (enable for non-fire 24 hour zone) 6 Delay 2 zone (enable to follow Timer 1 Entry / Exit times)
3 Keyswitch zone 7 Interior (Enable for auto bypass or stay arming)
4 Follower (enable for burglary zones that are
instant during non-entry times)
8 Local Only (enable if zone is not to be reported)
Segment 2 (Circle Numbers To Program)
1 Keypad audible on alarm 5 Bypassable
2 Yelping siren on alarm
6 Group Shunt
3 Steady siren on alarm 7 Force armable
4 Chime 8 Entry Guard
Segment 3 (Circle Numbers To Program)
1 Fast Loop Response
5 Dialer Delay zone
2
Double End of Line Tamper zone
6 Swinger zone
3 Trouble zone (Fire and Day zone) 7 Restore reporting
4 Cross Zone
8 Listen-In
Segment 4 (Circle Numbers To Program)
1 Zone activity monitor 5 Reserved
2 End of line resistor defeat 6 Reserved
3 Zone acts as request to exit input 7 Reserved
4 Zone acts as acces control zone 8 Reserved
Segment 5 (Circle Numbers To Program)
111 73
1-8
Reserved
THE DEFAULTS LISTED IN THE ODD-NUMBERED LOCATIONS BELOW REPRESENT THE FIVE SEGMENTS OF EACH OF
THOSE LOCATIONS. USE THE FIVE SEGMENT CHARTS FROM LOCATION 111 TO UNDERSTAND THESE DEFAULTS.
CONFIGURATION GROUP 2 ALARM EVENT CODE 112 74
2
113 74 CONFIGURATION GROUP 2 CHARACTERISTIC SELECT
2-125-278
114 74 CONFIGURATION GROUP 3 ALARM EVENT CODE
7
115 74 CONFIGURATION GROUP 3 CHARACTERISTIC SELECT
5-125-25678
116 74 CONFIGURATION GROUP 4 ALARM EVENT CODE
5
117 75 CONFIGURATION GROUP 4 CHARACTERISTIC SELECT
45-125-25678
118 75 CONFIGURATION GROUP 5 ALARM EVENT CODE
5
119 75 CONFIGURATION GROUP 5 CHARACTERISTIC SELECT
457-125-25678
120 75 CONFIGURATION GROUP 6 ALARM EVENT CODE
4
121 75 CONFIGURATION GROUP 6 CHARACTERISTIC SELECT
0-125-25678
122 75 CONFIGURATION GROUP 7 ALARM EVENT CODE
0
123 75 CONFIGURATION GROUP 7 CHARACTERISTIC SELECT
2-5-278
124 76 CONFIGURATION GROUP 8 ALARM EVENT CODE
1
125 76 CONFIGURATION GROUP 8 CHARACTERISTIC SELECT
1-13-378
126 76 CONFIGURATION GROUP 9 ALARM EVENT CODE
7
127 76 CONFIGURATION GROUP 9 CHARACTERISTIC SELECT
6-125-25678
128 76 CONFIGURATION GROUP 10 ALARM EVENT CODE
13
129 76 CONFIGURATION GROUP 10 CHARACTERISTIC SELECT
24-12-78
130 76 CONFIGURATION GROUP 11 ALARM EVENT CODE
3
131 77 CONFIGURATION GROUP 11 CHARACTERISTIC SELECT
3-0-2
132 77 CONFIGURATION GROUP 12 ALARM EVENT CODE
5
133 77 CONFIGURATION GROUP 12 CHARACTERISTIC SELECT
457-125-245678
134 77 CONFIGURATION GROUP 13 ALARM EVENT CODE
4
135 77 CONFIGURATION GROUP 13 CHARACTERISTIC SELECT
0-1258-25678
136 77 CONFIGURATION GROUP 14 ALARM EVENT CODE
7
137 77 CONFIGURATION GROUP 14 CHARACTERISTIC SELECT
5-1256-25678
NX-8-EUR Installation manual Page 100 02/07/06
