APPENDIX 3: EXPANDER NUMBERS FOR REPORTING
EXPANDER TROUBLE
The tables below list the device numbers that will be reported for each expander/keypad where a trouble condition
is present. For trouble conditions relating to the control panel, the device number is “0”.
Keypads
KEYPAD PART 1 PART 2 PART 3 PART 4 PART 5 PART 6 PART 7 PART 8
1 192 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255
Remote power supply NX-320E
Power supply DIP 1 DIP 2 DIP 3 Expander number
reported
1 OFF OFF OFF 84
2 ON OFF OFF 85
3 OFF ON OFF 86
4 ON ON OFF 87
5 OFF OFF ON 88
6 ON OFF ON 89
7 OFF ON ON 90
8 ON ON ON 91
Wireless receiver NX-448E
Wireless receiver DIP 1 DIP 2 DIP 3 Expander number
reported
1 OFF OFF OFF 35
2 ON OFF OFF 36
3 OFF ON OFF 37
4 ON ON OFF 38
5 OFF OFF ON 39
6 ON OFF ON 32
7 OFF ON ON 33
8 ON ON ON 34
NX-8-EUR Installation manual Page 110 02/07/06
